Columns
Column | Type | Size | Nulls | Auto | Default | Children | Parents | Comments | ||
---|---|---|---|---|---|---|---|---|---|---|
id | BIGINT | 19 | √ | null |
|
|
||||
gradeid | BIGINT | 19 | 0 |
|
|
|||||
x | BIGINT | 19 | √ | 0 |
|
|
x-position of the top-left corner of the comment (in pixels - image resolution is set to 100 pixels per inch) |
|||
y | BIGINT | 19 | √ | 0 |
|
|
y-position of the top-left corner of the comment (in pixels - image resolution is set to 100 pixels per inch) |
|||
width | BIGINT | 19 | √ | 120 |
|
|
width, in pixels, of the comment box |
|||
rawtext | LONGTEXT | 2147483647 | √ | null |
|
|
Raw text of the comment |
|||
pageno | BIGINT | 19 | 0 |
|
|
The page in the PDF that this comment appears on |
||||
colour | VARCHAR | 10 | √ | black |
|
|
Can be red, yellow, green, blue, white, black |
|||
draft | TINYINT | 3 | 1 |
|
|
Is this a draft comment? |
Indexes
Constraint Name | Type | Sort | Column(s) |
---|---|---|---|
PRIMARY | Primary key | Asc | id |
assieditcmnt_gra2_ix | Performance | Asc | gradeid |
assieditcmnt_grapag2_ix | Performance | Asc/Asc | gradeid + pageno |
