Columns
Column | Type | Size | Nulls | Auto | Default | Children | Parents | Comments | ||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
id | BIGINT | 19 | √ | null |
|
|
||||||||||||||||||||
shortname | VARCHAR | 100 | √ | null |
|
|
Shortname of a competency |
|||||||||||||||||||
description | LONGTEXT | 2147483647 | √ | null |
|
|
Description of a single competency |
|||||||||||||||||||
descriptionformat | SMALLINT | 5 | 0 |
|
|
The format of the description field |
||||||||||||||||||||
idnumber | VARCHAR | 100 | √ | null |
|
|
||||||||||||||||||||
competencyframeworkid | BIGINT | 19 | null |
|
|
The framework this competency relates to. |
||||||||||||||||||||
parentid | BIGINT | 19 | 0 |
|
|
The parent competency. |
||||||||||||||||||||
path | VARCHAR | 255 |
|
|
Used to speed up queries that use an entire branch of the tree. Looks like /5/34/54. |
|||||||||||||||||||||
sortorder | BIGINT | 19 | null |
|
|
Relative sort order within the branch |
||||||||||||||||||||
ruletype | VARCHAR | 100 | √ | null |
|
|
||||||||||||||||||||
ruleoutcome | TINYINT | 3 | 0 |
|
|
|||||||||||||||||||||
ruleconfig | LONGTEXT | 2147483647 | √ | null |
|
|
||||||||||||||||||||
scaleid | BIGINT | 19 | √ | null |
|
|
||||||||||||||||||||
scaleconfiguration | LONGTEXT | 2147483647 | √ | null |
|
|
||||||||||||||||||||
timecreated | BIGINT | 19 | null |
|
|
The time this competency was created. |
||||||||||||||||||||
timemodified | BIGINT | 19 | null |
|
|
The time this competency was last modified. |
||||||||||||||||||||
usermodified | BIGINT | 19 | √ | null |
|
|
The user who last modified this competency |
Indexes
Constraint Name | Type | Sort | Column(s) |
---|---|---|---|
PRIMARY | Primary key | Asc | id |
comp_comidn2_uix | Must be unique | Asc/Asc | competencyframeworkid + idnumber |
comp_rul2_ix | Performance | Asc | ruleoutcome |
